RECCO SURGICAL, is manufacturer of Mortuary Chamber
for storing cadaverous under low temperature cool conditions in order to prevent
decomposition.Mortuary chambers have multiple names such as dead body freezer, mortuary
cabinets, mortuary freezers, dead body storage freezer and body storage freezer.
Mortuary Chamber Cabinet are double walled with outer made of SS 304 and inner walls
made of SS 316. Tray is made of SS 304 to carry dead bodies. Trays of our Dead Body
Cabinet travel on rollers fitted with ball bearings for easy movement. We provide
hermetically sealed compressor Serves Refrigeration Unit and air conditioner unit
use VOLTAS, BLUE STAR etc.
We provide digital microprocessor temperature indicator cum Controller to show temperature.
Temperature range of morturay chmaber are -2°C to 10°C AND 8°C to -10°C CUSTOMISED .
Mortuary cabinets have a wide application and are used in hospitals, airports, research
centers and many other agencies that may have a requirement to preserve a human
body before being used in research or transported to destination.
The primary use of a mortuary chamber is to store and prevent
a body from decomposing rapidly. Sometimes, it happens that a body has to be kept
for long duration because of unexpected circumstances.
Technical specification of 4 Body Mortuary Cooling Chamber:
-
Chamber storage temperature (-2°L to 10°C AND 8°C to -10°C Cooling)
-
-
Inner/outer cabinet is made of stainless steel grade ss304.(Sturcly construction)
-
Puff insulation 100mm
-
Microprocessor based temperature controller
-
The cooling chamber system should be fans shut off & Interior proper LED
lighting ON during door opening.
-
Audio visual alarm for high & low temperature.
-
Dead bodies trays with handles and travel roller fitted with ball bearing.
-
The floor constructed out hardened and rain forced steel sheets containing spills
for easy cleaning & hygiene(proper drain provide)
-
Energy efficient & low maintenance
-
Front panel of the units comprises of on/off switches cooling and main indication
lamps, temperature controller, voltmeter, ammeter
-
Interior led lighting
-
Casters Swivel licking castors
-
Superior engineered frame for maximum rigidity and low noise level<60dB
-
Strong and reliable with powerful quick response quick response refrigeration,
and exclusive ling life process is an unique feature of mortuary cabinet
-
Heavy duty air cooled non CFC compressor
-
Auto defrosting system
-
ALL control like 1 pc, hpc, volt guard protection etc should be provide
-
The condensing unite & outdoor unit is around 10-20 feet
-
Warranty period minimum one year
TECHNICAL SPECIFICATIONS
| Model
|
RECC-MC01
|
| Design
|
Rectangular Horizontal Type
|
| Construction
|
Double Walled
|
| Working temperaturer
|
-2°L to 10°C AND 8°C to -10°C
|
| Internal Chamber
|
Stainless Steel SS 316
|
| External Chamber
|
Stainless Steel 304 Grade
|
| Tray
|
Stainless Steel 304 Grade
|
| Finishing
|
Mirror finished inner and external surface
|
| Door Custruction
|
SS 304
|
| Insulation
|
Puf 60mm
|
| Sterilization Period
|
25 to 30 Minutes
|
| Temperature Sensor
|
PT100
|
| Display
|
LCD/LED
|
| Refrigerant(Condenser)
|
Cfc free
|
| Air Circulation(Condenser)
|
Efficient condenser with automatic evaporating system (condensate) Forced
|
| Controller(temperature)
|
PID
|
| Body Capacity
|
1/2/3/4/6 (Customised)
|
| Power Supply
|
220 V & 50/60 Hz
|
| Cluster Wheel
|
Lockable
|
