RECCO SURGICAL are leading manufacturer, supplier
and exporter of laminar air flow. we manufacturing Laminar Air Flow such as Vertical
Laminar Air Flow and Horizontal Laminar Air Flow.A laminar air flow workstation
is a closed cabinet fitted with HEPA filtered air flow system.
Laminar means unidirectional constant flow of air with almost no or minimal turbulence.
The air flow velocity remains between 0.3 m/s to 0.5 m/s. The purpose of using such
workstations in laboratory is to create particle and bacteria free working environment
to carry out specialized work. As these units discharge air towards user, they provide
no personal protection but product protection from room contaminants
Laminar Flow Cabinets, or laminar air flow cabinets as they are also known, are
normally made of stainless steel with no gaps or joints thereby preventing the build-up
of bacteria from collecting anywhere in the working zone.
Laminar Flow Cabinets are also known as clean benches because the air for the working
environment is thoroughly cleaned by the precision filtration process.
HORIZONTAL LAMINAR AIR FLOW Cabinets receive their
name due to the direction of air flow which comes from above but then changes direction
and is processed across the work in a horizontal direction. The constant flow of
filtered air provides material and product protection.
VERTICAL LAMINAR AIR FLOW Cabinets function equally
well as horizontal Laminar Flow Cabinets with the laminar air directed vertically
downwards onto the working area. The air can leave the working area via holes in
the base. Vertical flow cabinets can provide greater operator protection.
HEPA FILTER filtered air through pre filter is forwarded
towards HEPA FILTER. HEPA FILTER offers 99.99% efficiency for 0.3 micron particulates.
LAMINAR
AIR FLOW APPLICATIONS:
-
Life
science research
-
-
Microbiology
-
Pathology
lab
-
Tissue
culture
-
Pharmaceutical
-
Musroom
Spam Lab
-
Laboratory
-
Electronic
and industrial sectors
TECHNICAL SPECIFICATIONS
Model
|
RECC-LAF01
|
Design
|
Rectangular Horizontal Type
|
Construction
|
SS 304 / Powder coated MS / GI sheet
|
Air flow direction
|
Horizontal/ Vertical
|
Pre-Filter -
|
10 microns (washable)
|
HEPA filter
|
0.3 Microns( not washable it will change in 12 to 18 months)
|
Air velocity
|
0.45 m/s to 0.65 m/s
|
Front Door
|
Manual made by Acrylic transparent seat
|
Finishing
|
Mirror finished inner and external surface
|
Door
|
Single Door
|
Power Supply
|
220 volts / 50 Hz
|
SIZE OF LAMINAR AIR FLOW
SIZE IN MM
W x H x D
|
SIZE IN FEET W x H x D
|
CAPACITY IN LTR
|
HEPA FILTER SIZE/No.
|
No. OF PRE-FILTER
|
600x600x600
|
24" x 24" x 24"
|
216LTR
|
2FT x 2FT x 6Inch / #1
|
#1
|
900x600x600
|
36" x 24" x 24"
|
325LTR
|
3FT x 2FT x 6Inch / #1
|
#2
|
1200x600x600
|
48" x 24" x 24"
|
430LTR
|
4FT x 2FT x 6Inch / #1
|
#2
|
1800x600x600
|
72" x 24" x 24"
|
650LTR
|
3FT x 2FT x 6Inch / #2
|
#3
|
2400x600x600
|
96" x 24" x 24"
|
870LTR
|
4FT x 2FT x 6Inch / #2
|
#4
|
